ac gate loop detector Gate Automation Dual Channel

TMT loop saudi arabia detector Gate Barrier Gate Motor Dual Channel 12-24V AC TMT Global   ac gate loop detector Gate Automation Dual Channel   in recent years have become a popular tool having innumerable applications in policing,loop detector best loop detector Gate Automation Dual Channel tmt-7762 TMT Global Technology LTD aims to provide the best quality products r Structured Cabling Systems Copper And Fiber Optics Range Access Control Systems Gate automation Technical Parameters Product Name: Loop Detector Self-turning range: 20-2000μH Response Times: Turn-on 10-90MS Turn-off 10-90MS Sensitivity: 16 way selectable , Highest 0.010% DL/L , Lowest 2.56% DL/L Power Requirements: 110-240VAC (48 to 62Hz) 12-24VADC(48 to 62Hz) Visual Indications: Power LED-Red,  Channel LED-Green Reset: Reset by push button on front of enclosure Frequency Four step switch selectable 20-80KHz Relay Output: Presence Relay/Fault Relay Voltage tolerance : AC 10% / -15% Voltage tolerance : DC±15% Device Channel: Single /Double Operating temperature: 40℃ to 70℃ (-111℉ to 158℉) Sensitivity : 4 levels adjustable Relative Humidity: <95% Application: open gate, match with barrier gate, gate opener etc. General Specification Product Name: Loop Detector Self-turning range; 20-2000μH Response Times :Turn-on 10-90MS Turn-off 10-90MS Power Requirements: 110-240VAC (48 to 62Hz) 12-24VADC(48 to 62Hz) Visual Indications: Power LED-Red, Channel LED-Green Frequency: Four-step switch selectable 20-80KHz Relay Output: Presence Relay/Fault Relay Voltage tolerance : AC 10% / -15% Device Channel: Double Application: open gate, match with barrier gate, gate opener etc Model No. : TMT-7762
